3d max modeling request

[+Wrench]

in other words, 'help a brudda out'



what I need from our 3d guys, is actually quite simple



I need the 'bow and arrow' diapole antenna as seen in the profile below. mind you, the NF.IIs did have other reciever/transmitter antennas on the wings (8 in total), but I think we might be able to live without them (as measuring the exact distances to the mid-wing and wingtips might be diffucult)



a simple lod, that I can add via fake pilot.

the rest I'll reuse from the NF XII



thanks!

Edited April 5, 2013 by Wrench

[+RAVEN]

Are the Vertical sections,Round, Flat or airfoil?

[+RAVEN]

Try This.

Ant.zip

[+Wrench]

the diagrams in the modlers data file, and the photos suggest simple cyilnders



I'll test that lod ASAP!!



thanks Raven!

[+Wrench]

I'd say that works!!



was even able to bury 2 into the wings to 'fake create' the reciever diapoles!!



thanks man!



now, just reskinning and redecaling!

[+RAVEN]

Cool. I took a chance on the shape. If you want I could export just the vertical section for the wings? ,Or if you give me the location data from the FM I could make it all one mesh, I have the aircraft to test it with.

[+Wrench]

up to my friend! it works fine as is!!! (I REALLLY thank you!)

using it 3 times was super easy to add as 'seats' for the fake pilot





if you realy want something to do....after you finish the P-40, you want to finish an F6F-5 Hellcat (and maybe make a -3 from it?)? Got it from Zur (the Great and Powerful); already mapped and animated for SF. even has a skin. Just hasn't been exported to LOD

no hurry on answering....

(ain't I a stinker??? )



anyway, here are the 'seat' position from nose and both wing mounts



[RadarAnt1]

SystemType=PILOT_COCKPIT

PilotModelName=FakePilot

Position=0,0,0

SeatModelName=NF2Ant

SeatPosition=7.05,0.03,0.42

SeatID=3



[RadarAnt2]

SystemType=PILOT_COCKPIT

PilotModelName=FakePilot

Position=0,0,0

SeatModelName=NF2Ant

SeatPosition=-7.05,0.03,0.42

SeatID=4



[RadarAnt3]

SystemType=PILOT_COCKPIT

PilotModelName=FakePilot

Position=0,0,0

SeatModelName=NF2Ant

SeatPosition=0.0,3.60,-0.28

SeatID=5



ant 3 is the nose (obviously!). Only if you to! We want the P-40!!

[+RAVEN]

The F6F-5 Hellcat sounds like fun. I.m doing the lines and FM for the E and testing the guns.
